30mm to 200mm Panel Thickness Composite Insulated Sandwich Panel
This high-performance insulated sandwich panel is specifically designed for cold storage and clean room wall systems, providing superior thermal insulation, structural strength, and fire resistance for modern construction projects.
Product Overview
Our composite insulated sandwich panel features customizable thickness ranging from 30mm to 200mm, making it ideal for various architectural and industrial applications. The metal-faced construction combines durability with excellent insulation properties, while the wide thickness selection ensures optimal performance for specific insulation and structural requirements.
Key Features
- Panel Thickness Range: 30mm to 200mm
- Foam Thickness Options: 30mm, 40mm, 50mm
- EPS Core Thickness: 50mm to 150mm
- Fire Resistance: Class A1 to B2 (depending on core material)
- Panel Width: 1000mm to 1200mm
- Custom Lengths: Up to 12 meters
- Density: 6-25 kgs/m³
- Pitch: 205mm
- Advantages: Superior heat and sound insulation
Technical Specifications
| Density |
6-25 kgs/m³ |
| Color Options |
RAL Color Range Available |
| Steel Sheet Material |
Color Galvanized Steel |
| Pitch |
205 mm |
| Panel Thickness |
30 mm - 200 mm |
| Steel Plate Thickness |
0.3 - 0.6 mm |
| EPS Thickness |
50 - 150 mm |
| Fire Class |
B15 |
| Purpose |
Decorative Finishing |
| Fire Resistance |
Class A1 to B2 (depending on core material) |
Applications
These insulated panels are extensively used in cold storage facilities, clean rooms, warehouses, commercial buildings, and residential construction. Their excellent thermal insulation properties reduce energy consumption for heating and cooling, while the lightweight structure allows for faster installation and reduced structural load.
Customization Options
We offer comprehensive customization services including panel lengths up to 12 meters, various color options from the RAL color range, and multiple fire resistance classifications from Class A1 to B2 based on your specific core material requirements.
Support & Services
Our technical support team provides product selection guidance, installation assistance, and troubleshooting. We offer professional installation services, detailed maintenance guidelines, and warranty coverage for manufacturing defects to ensure optimal panel performance and longevity.
Frequently Asked Questions
- What is an Insulated Sandwich Panel?
A high-performance building material consisting of two outer metal sheets with an insulating core, designed for excellent thermal insulation and structural strength.
- What insulation cores are available?
We offer panels with various core materials including polyurethane (PU), polyisocyanurate (PIR), and rock wool to meet different insulation and fire resistance requirements.
- How do these panels improve energy efficiency?
The insulated core significantly reduces heat transfer, helping maintain indoor temperatures and reducing energy consumption for heating and cooling systems.
- What applications are suitable for these panels?
Ideal for cold storage facilities, clean rooms, industrial buildings, commercial warehouses, and residential construction where thermal insulation and quick installation are essential.
